10 Advanced Usage
10 - 22
Vision System FH/FHV/FZ5 Series User’s Manual (Z365)
In the following cases, the system operates in Non-Multi-input mode, regardless of the settings
for Mode.
• Camera Image Input HDR or Camera Image Input HDR Lite is used.
• Multiple Input image processing items are used in one Multi-trigger Imaging Task block.
•FZ-SQ camera is used with its light ON.
• Input image processing item is inserted outside of the range between Multi-trigger Imaging
and Multi-trigger Imaging End processing items.
There are restrictions below when FZ-FQ camera is used with its light ON.
• All Camera Image Input processing items operate with the settings for the Camera Image
Input of the first Multi-trigger Imaging Task in the flow.
• The system operates in Non-Multi-input mode. (It takes longer time to turn ON the READY
signal).
• When the light of FZ-FQ camera is OFF, the camera operates in the same way as
other camera does.
Timeout 1 to 60 s
[10]
Set the time for timeout of Multi-trigger Imaging Task block.
It is a wait time between a Multi-trigger Imaging Task and the next
one.
When a STEP signal is not input within the timeout time after the
READY signal turns ON, the Multi-trigger Imaging unit judgment
will be NG.
Setting item
Set value
[Factory default]
Description
