Omron fh-1 series User Manual

5 - 55
5 Creating Measurement Scenes
Vision System FH/FHV/FZ5 Series User’s Manual (Z365)
5-5 Using Variables to Edit the Flow [TDM Editor]
5
5-5-4 Using Variables
3 Click [Move].
The current cursor on the “Value” column will be moved to the cell on the “Value” column of the
element number searched. The following example is that the number of one-dimensional ele-
ment number is “1”, the number of two-dimensional elements is “2”, and the number of three-
dimensional elements is “3”.
4 Click the cell to enter the value.
Additional Information
The following operation also enables values to enter into cells in the “Value” column.
• Drag the scroll bar of the “Value set form” dialog box for the three- or more dimensional array
type to find a cell to set the initial value. Click the cell to enter the value.
