6 Performing Measurement and Adjustment
6 - 36
Vision System FH/FHV/FZ5 Series User’s Manual (Z365)
If you need to modify the judgement conditions for more than one processing unit, repeat steps
6 to 8.
 Disabling the Simplified Non-stop Adjustment Mode
If the Simplified Non-stop Adjustment Mode is enabled, you cannot make detailed parameter settings
for processing units.
To make detailed parameters for processing units, stop the measurement process and disable the Sim-
plified Non-stop Adjustment Mode.
1 Select [Layout modification] from the [Window] menu.
2 In the [Layout number] on the Layout Modification Pane, select the layout number for which to
disable the Simplified Non-stop Adjustment Mode.
3 Click the upper right corner of the Flow Display Pane.
4 Change the [Unit setting mode] under [Flow Windows_Setting] to [Normal], and then click the
[OK] button.
5 Click [Layout ended] on the Layout Modification Pane.
Simplified Non-stop Adjustment Mode is disabled for the modified Layout Window.
Important
• While Simplified Non-stop Adjustment Mode is being executed, do not switch the scenes or
execute scene group switching.
• Simple Non-stop Adjustment Mode can be applied to judgment conditions; for processing
items that do not have judgment conditions, Simple Non-stop Adjustment Mode can not be
used.
