Omron fh-1 series User Manual

7 - 11
7 Increasing/Switching Measurement Scenes
Vision System FH/FHV/FZ5 Series User’s Manual (Z365)
7-5 Saving Scene Groups in External Storage [Scene Group Saving Destination Settings]
7
3 Set each item in the [External storage device settings] area.
4 Click [OK].
The scene group storage location is changed, and the current scene group data is transferred
from the current storage location to the new storage location. An error message is displayed if
the transfer fails.
Important
• An error message is displayed if scene group data storage or reading fails. See ”Error Mes-
sages and Troubleshooting” in the Appendices for descriptions of error messages.
Refer to 11-1 Error Messages and Troubleshooting on page 11-2.
• When the scene group data storage location setting is changed, a file with the [*.scg] file
extension is created at the new storage location. Do not change the file name or file exten-
sion of this scg file. If you change, the setting will not be saved or read correctly.
• When you change the Scene group save destination, the original data in the save destination
will be deleted. The data in the original save destination will be deleted. Make sure to back up
data for use in case of malfunction, or corrupted data.
• The Sensor Controller may fail to load a scene group at the Sensor Controller start-up
because a recognition delay for external storage happens depending on models or number
of connections of external storage. Use the Device Information Storage Tool when saving a
scene group data to external storage.
Refer to 3-6-2 Device Information Storage Tool on page 3-35.
Additional Information
• You can check the available capacity of the external storage in the setting screen. We recom-
mend that you check whether your external storage has enough available capacity before
changing the storage location.
• Clicking [Restore the defaults] restores the settings to their factory default values.
Factory default settings differ as follows:
• FZ5-L series/FZ5-600 series:
Scene group 0 is stored in the Sensor Controller's flash memory.
Scene groups 1 and after are stored in the external storage.
• FH series/FZ5-800/1100/1200 series:
Scene group 0, Scene group 1, and after are stored in the Sensor Controller's flash mem-
ory.
Scene group No. 0 to 9999[1] This setting is valid when [Save after the next scene
group data in the external storage device] is selected for
[Scene Group Saving Destination Setting].
Used to set the number of the first scene group to store
in the external storage.
For the FH/FHV/FZ5 series, if 32 or above is specified
for the scene group number, all scene group data will be
saved to the Sensor memory.
Variable name Set value [Factory default] Content
External storage
device settings
--- This setting is valid when [Save all scene group data in
the external storage device] or [Save after the next
scene group data in the external storage device] is
selected for [Scene Group Saving Destination Setting].
Used to set the storage location folder.
Variable name Set value [Factory default] Content
