8 Setting Windows
8 - 52
Vision System FH/FHV/FZ5 Series User’s Manual (Z365)
Important
• In [Control], if using a macro RaiseOptionEvent to operate, then specify the control command
in the event number, and the control parameters in the parameter.
• The text display window is updated in the event of the following.
Cell data update event because of a RaiseOptionEvent
Data identifier/
number/variable
[Blank] This item is available when other than [Direct input] is selected
in [Data type].
Setting contents vary depending on the [Data type]. Up to 32
characters can be input.
1. Unit data: External reference number or identifier name
2. Scene variable/System variable: Variable name
3. System data/Global data: Identifier name
Value type • [String]
• Number
Specifies the data type.
Align • [Left]
•Center
• Right
Sets the character display position.
Status Sets the window part status.
Front/Back [Blank] Specifies the variable to store the text display window status
from the variable assignment window.
However, only the scene variable or system variable can be
specified.
When the variable value is:
Positive: Move window to the front.
Negative: Move window to the back.
0: Do not move the window.
Control Sets when changing the status for the processing item setting
window display button using a macro.
Command ID 0 to 999 [0] The ID used to identify the operation target when using the
macro RaiseOptionEvent relationship to carry out operations.
Text Setting The set contents of [Font Setting] and [Color Setting] are dis-
played in the display setting area.
Font Setting Sets the display font.
Size 1 to 100 [10] Sets the font size.
Style • Bold
• Italic
• Underline
• Strikeout
Sets the font style.
Check the box to set desired style.
Color Setting • [Text color]
• Background
color
• Text color (NG)
• Background
color (NG)
Sets the background color when it is selected, font color, and
background color.
Text color: Set the character color in OK state.
Background color: Set the character background color in
OK state.
Text color (NG): Set the character color in NG state.
Background color (NG): Set the character background color in
NG state.
R: 0 to 255 [16]
G: 0 to 255 [16]
B: 0 to 255 [16]
Setting item
Setting value
[Factory default]
Description
