8 - 77
8 Setting Windows
Vision System FH/FHV/FZ5 Series User’s Manual (Z365)
8-4 Creating a Custom Dialog Box [Custom Dialog Functions]
8
8-4-2 Custom Dialog Tool
Unit label • [Unchecked]
• Checked
This is available when [Unit data (No.)] or [Unit data (ident)] is
selected in the “Data Type”.
Sets when [Unit data (No.)] or [Unit data (ident)] is selected in
the “Data Type”.
When using the unit label to specify the unit to be the target for
the numeric setting, select this and set the unit label.
Target data No. This is available when [Unit data (No.)] is selected in the “Data
Type”.
Specifies the data to be the target for the numeric setting.
Enter the data number for the unit that is specified by the “Tar-
get unit No.”.
[Data reference]
button
This is available when [Unit data (No.)] is selected in the “Data
Type”.
You can select the data number directly to enter it, or you can
enter it with the [Data reference] button.
Click the [Data reference] button to select the target data in the
[Data reference] dialog box.
Data ident Sets when [Unit data (ident)] is selected in the "Data Type".
Use the unit data (identifier name) to specify the unit to be the
target for the numeric setting.
Ident 0
Ident 1
These are available when [System data] is selected in the
“Data Type”.
Specifies the system data to be the target for the numeric set-
ting using the identifier information 0 and identifier information
1.
(Refer to the Vision System FH/FZ5 Series Macro Customize
Functions Programming Manual (Cat No. Z367-E1) system
data list.)
Scene variable This is available when [Scene variable)] is selected in the “Data
Type”.
Specifies the scene variable to be the target for the numeric
setting using the scene variable name.
System variable This is available when [System variable)] is selected in the
“Data Type”.
Specifies the system variable to be the target for the numeric
setting using the system variable name.
Decimal digits 0 to 4
[4]
Enter the number of digits after the decimal place that can be
entered by the numeric setting.
Max value −999999.9999 to
999999.9999
[999999.9999]
Enter the maximum value that can be entered with the numeric
setting.
Min value −999999.9999 to
999999.9999
[−999999.9999]
Enter the minimum value that can be entered with the numeric
setting.
Setting item
Setting value
[Factory default]
Description
