9 Saving/Loading Data
9 - 16
Vision System FH/FHV/FZ5 Series User’s Manual (Z365)
The following is the detailed list of the setting data.
Setting data which can be backed up
Type Name Description
Setting data of the
line
System setting System setting includes the following configuration.
• The data of [System Settings] dialog box
Refer to 4 Setting the Controller on page 4-1.
• The layout information of the layout 0 to 8
Refer to 8-3 Arranging Windows [Layout Functions] on page 8-14.
(*1)
• The User Data
Refer to A-12 Sharing Data Within the Controller [User Data Tool]
on page A-37.
System variables They are enabled within a defined line settings.
Although they can be set and referenced across scenes and
scene groups, they cannot be set and referenced in different lines
with multiple line random modes.
For details, refer to 5-5-1 Edit Flow Screen on page 5-14 and 5-5-4
Using Variables on page 5-43.
Scene group saving
destination
Setting contents of the Scene grope saving destination are the set-
ting object.
Refer to 7-5 Saving Scene Groups in External Storage [Scene
Group Saving Destination Settings] on page 7-10.
Scene group
Scene grope saved to Sensor Controller or external memory
(*2)
are the setting object.
All of the following settings include to Scene grope
• Flow Settings of all scenes.
• Macro code of Scene Control Macro for all Scene.
• Scene Control Macro data of all Scenes.
Refer to Components of the Setting Screen of the Communica-
tion Command Macro Tool and How to Configure Settings in the
Vision System FH/FZ5 Series Macro Customize Functions Pro-
gramming Manual (Cat. No. Z367)
• Image Container Window Settings of all scenes
Refer to 8-3 Arranging Windows [Layout Functions] on page 8-
14.
• Image Window Settings of all scenes.
Refer to 3-2-7 Changing the Image Mode and Other Display
Contents on page 3-24.
Communication
command macro
The target data is the Communication Command Macro data.
Refer to Components of the Setting Screen of the Communication
Command Macro Tool and How to Configure Settings in the Vision
System FH/FZ5 Series Macro Customize Functions Programming
Manual (Cat. No. Z367).
Custom dialog The target data is all setting of the Custom dialog.
Refer to 8-4 Creating a Custom Dialog Box [Custom Dialog Func-
tions] on page 8-67.
Security setting Security settings include the following configuration.
• Account list
• Layout restrictions
• Operating restrictions
Refer to 10-3-4 Saving/Loading/Deleting the Security Settings
on page 10-36.
To Next Page
