Alignment is supported for the following external devices.
Supported External Devices
Type
Stages X(Y)
Xθθ axis: Direct drive Camera axis movement: None
Camera axis movement: X axis
θ axis: Linear drive Camera axis movement: None
Camera axis movement: X axis
Yθθ axis: Direct drive Camera axis movement: None
Camera axis movement: Y axis
θ axis: Linear drive Camera axis movement: None
Camera axis movement: Y axis
θX θ axis: Direct drive Camera axis movement: None
Camera axis movement: X axis
θ axis: Linear drive Camera axis movement: None
Camera axis movement: X axis
θY θ axis: Direct drive Camera axis movement: None
Camera axis movement: Y axis
θ axis: Linear drive Camera axis movement: None
Camera axis movement: Y axis
XY
XYθθ axis: Direct drive Camera axis movement: None
Camera axis movement: X axis
Camera axis movement: Y axis
Camera axis movement: XY axes
θ axis: Linear drive Camera axis movement: None
Camera axis movement: X axis
Camera axis movement: Y axis
Camera axis movement: XY axes
θXY θ axis: Direct drive Camera axis movement: None
Camera axis movement: X axis
Camera axis movement: Y axis
Camera axis movement: XY axes
XYθθ axis: Linear drive Camera axis movement: None
Camera axis movement: X axis
Camera axis movement: Y axis
Camera axis movement: XY axes
UVW Direct fulcrum motion
Rotary fulcrum motion
UVWR Direct fulcrum motion
Rotary fulcrum motion
Robots 3 axes
4 axes Control method: Fixed positions
Control method: Measured positions
