10 Advanced Usage
Vision System FH/FHV/FZ5 Series User’s Manual (Z365)
10-9 Positioning workpieces for stage and
robot applications [Alignment Function]
10
10-9-2 Execution of Calibration
Set the parameters that describe the type and specifications of the external device to use.
Add the following machine setting processing item to the flow.
 Stage Data
If you are using a stage, use this processing item.
Refer to Stage Data of the Vision System FH/FHV/FZ5 Series Processing Item Function Reference
Manual (Cat. No. Z341).
 Robot Data
If you are using a robot, use this processing item.
Refer to Robot Data of the Vision System FH/FHV/FZ5 Series Processing Item Function Reference
Manual (Cat. No. Z341).
The settings for the machine setting processing item can be referenced by the following processing
items.
• Vision Master Calibration
• PLC Master Calibration
• Transfer Position Data
• Calc Axis Move
• Calc Axis Move by Multipoint
Additional Information
The settings for the machine setting processing item can be referenced from other scenes.
The machine setting processing item can be registered only in one scene group, but it can be
referenced from other the scenes. This enables central management of the external device set-
tings.
