A-10 Memory Usage Guidance For Processing Items
A
Classification Approx. 41 KB Approx. 543,477 MB
(for monochrome
image)
Approx. 1,608,757 MB
(for color image)
Model registration count, model registra-
tion figure, model parameters, image size,
whether image is color or monochrome.
Edge Position Approx. 1 KB Approx. 1 MB Measurement region figure, image size.
Edge Pitch Approx. 5 KB Approx. 1 MB Measurement region figure, image size.
Scan Edge Position Approx. 2 KB Approx. 12 MB Measurement region figure, number of
measurement points, image size.
Scan Edge Width Approx. 2 KB Approx. 23 MB Measurement region figure, number of
measurement points, image size.
Circular Scan Edge Posi-
tion
Approx. 2 KB Approx. 42 MB Measurement region figure, number of
measurement points, image size.
Circular Scan Edge
Width
Approx. 2 KB Approx. 83 MB Measurement region figure, number of
measurement points, image size.
Intersection Approx. 4 KB Approx. 23 MB Measurement region figure, image size.
Color Data Approx. 1 KB Approx. 25 MB Measurement region figure, selected
region figure of static mask, image size.
Gravity and Area Approx. 1 KB Approx. 25 MB Measurement region figure, selected
region figure of static mask, image size.
Labeling Approx. 2 KB Approx. 25 MB Measurement region figure, selected
region figure of static mask, image size,
maximum number of labels.
Label Data Approx. 1 KB No change -
Defect Approx. 1 KB Approx. 51 MB Measurement region figure, selected
region figure of static mask, image size.
Precise Defect Approx. 20 KB Approx. 29 MB Measurement region figure, detection
parameter settings, selected region figure
of static mask, image size.
Fine Matching Approx. 1 KB Approx. 38 MB (for
monochrome image)
Approx. 63 MB
(for color image)
Model registration figure, image size,
whether image is color or monochrome.
Character inspection Approx. 4 KB No change -
Date Verification Approx. 1 KB Approx. 1 MB Length of character string, code parame-
ter settings.
Model Dictionary Approx. 4 KB Approx. 95,567 MB
(for monochrome
image)
Approx. 282,801 MB
(for color image)
Model registration count, model registra-
tion figure, model parameters, image size,
whether image is color or monochrome.
2DCode Approx. 12 KB Approx. 1 MB Length of comparison character string,
number and length of sorting comparison
character strings.
Barcode Approx. 3 KB Approx. 1 MB Length of comparison character string,
number and length of sorting comparison
character strings.
OCR Approx. 704
KB
Approx. 1 MB Number and length of character string for-
mats, number and length of comparison
strings, number and length of teaching
correct response values, code parameter
settings.
Item
Approximate memory usage
Main settings that affect change
of memory used
Adding to
measurement
flow
Change due to set-
tings
