Omron JX User Manual

3-28
3-6 Parameter List
3
Operation
Others
C145
Output terminal 11
OFF delay
0.0 to 100.0 0.0 No s 1154 4-60
C148
Relay output ON
delay
0.0 to 100.0 0.0 No s 1157 4-60
C149
Relay output OFF
delay
0.0 to 100.0 0.0 No s 1158 4-60
Control parameter
H003
Motor capacity
selection
200-V class
0.2/0.4/0.75/1.5/2.2/3.7/5.5/7.5
400-V class
0.4/0.75/1.5/2.2/3.7/5.5/7.5
Factory
default
No kW
1165
4-63
H203
*2nd motor capacity
selection
Factory
default
1541
H004
Motor pole number
selection
2
4
6
8
4
No Pole
1166
4-63
H204
*2nd motor pole
number selection
4 1542
H006
Stabilization
parameter
0. to 255.
100 Yes % 1168
4-63
H206
*2nd stabilization
parameter
100 Yes % 1544
Parameter
No.
Function name
Monitor or data range
(Digital Operator)
Default
setting
Change
during
Run
Unit
Modbus
Address
(Hex)
Page

Omron JX Specifications

General

Enclosure Rating	IP20
Output Frequency	0 to 400 Hz
Protection	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit
Communication	RS-485
Frequency Range	0.1 to 400 Hz
Power Rating	0.4 to 15 kW
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +65°C
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000 m above sea level
Output Voltage	3-phase 200 to 240 VAC, 3-phase 380 to 480 VAC
Cooling Method	Fan cooling
