Page #77 background image
3-27
3-6 Parameter List
3
Operation
Communication function adjustment
C070
Operator/ModBus
selection
02: Digital Operator
03: ModBus
02 No 1137
4-66C071
Communication
speed selection
(Baud rate selection)
04: 4800 bps
05: 9600 bps
06: 19200 bps
04 No 1138
C072
Communication
station No. selection
1. to 32. 1. No 1139
C074
Communication
parity selection
00: No parity
01: Even
02: Odd
00 No 113B
4-66
C075
Communication stop
bit selection
1: 1-bit
2: 2-bit
1No 113C
C076
Communication error
selection
00: Trip
01: Trip after deceleration stop
02: Ignore
03: Free run
04: Deceleration stop
02 No 113D
C077
Communication error
timeout
0.00 to 99.99 0.00 No s 113E
C078
Communication wait
time
0. to 1000. 0. No ms 113F
Various adjustment
C081 O adjustment 0.0 to 200.0 100.0 Yes % 1141 4-11
C082 OI adjustment 0.0 to 200.0 100.0 Yes % 1142 4-11
Others
C086 AM offset adjustment 0.0 to 10.0 0.0 Yes V 1145 4-62
C091 Not used
Use "00".
*Do not change.
00 ⎯⎯
C101 UP/DWN selection
00: Do not store the frequency data
01: Store the frequency data
00 No 1149 4-53
C102 Reset selection
00: Trip reset at rising edge of RS input
01: Trip reset at falling edge of RS input
02: Enabled only during trip (Reset at rising
edge of RS input)
00 No 114A 4-51
C141
Logic operation
function A input
00: RUN (signal during RUN)
01: FA1 (constant speed arrival signal)
02: FA2 (over set frequency arrival signal)
03: OL (overload warning)
04: OD (excessive PID deviation)
05: AL (alarm output)
06: Dc (disconnection detected)
07: FBV (PID FB status output)
08: NDc (network error)
10: ODc (
Do not use.
)
43: LOC (light load detection signal)
00 No 1150 4-59
C142
Logic operation
function B input
01 No 1151 4-59
C143
Logic operator
selection
00: AND
01: OR
02: XOR
00 No 1152 4-59
C144
Output terminal 11
ON delay
0.0 to 100.0 0.0 No s 1153 4-60
Parameter
No.
Function name
Monitor or data range
(Digital Operator)
Default
setting
Change
during
Run
Unit
Modbus
Address
(Hex)
Page
