Omron JX User Manual

3-26
3-6 Parameter List
3
Operation
Multi-function input terminals
C011
Multi-function input 1
operation selection
00: NO
01: NC
00
No ⎯
110B
4-44
C012
Multi-function input 2
operation selection
00 110C
C013
Multi-function input 3
operation selection
00 110D
C014
Multi-function input 4
operation selection
00 110E
C015
Multi-function input 5
operation selection
00 110F
Multi-function output setting
C021
Multi-function output
terminal 11 selection
00: RUN (signal during RUN)
01: FA1 (constant speed arrival signal)
02: FA2 (over set frequency arrival signal)
03: OL (overload warning)
04: OD (excessive PID deviation)
05: AL (alarm output)
06: Dc (disconnection detection)
07: FBV (PID FB status output)
08: NDc (network error)
09: LOG(logic operation output)
10: ODc (Do not use.)
43: LOC (light load detection signal)
00
No ⎯
1114
4-55
C026
Relay output (AL2,
AL1) function
selection
05 1119
C028 AM selection
00: Output frequency
01: Output current
00 No ⎯ 111B 4-62
C031
Multi-function output
terminal 11 contact
selection
00: NO contact at AL2; NC contact at AL1
01: NC contact at AL2; NO contact at AL1
00
No ⎯
111D
4-61
C036
Relay output (AL2,
AL1) contact
selection
01 1122
C038
Light load signal
output mode
00: Enabled during acceleration/deceleration/
constant speed
01: Enabled only during constant speed
01 No ⎯ 1178 4-60
C039
Light load detection
level
0.0 to 2.0 × Rated current (0.0 setting: Function
disable)
Rated
current
No ⎯ 1179 4-60
Level output status setting
C041
Overload warning
level
0.0: Does not operate
0.1 × Rated current to 2.0 × Rated current
Rated
current
No A
1124
4-33
C241
*2nd overload
warning level
Rated
current
153A
C042
Arrival frequency
during acceleration
0.0 to 400.0 0.0 No Hz 1126 4-56
C043
Arrival frequency
during deceleration
0.0 to 400.0 0.0 No Hz 1128 4-56
C044
PID deviation
excessive level
0.0 to 100.0 3.0 No % 1129 4-22
C052 PID FB upper limit
0.0 to 100.0
100
No %
112E
4-22
C053 PID FB lower limit 0.0 112F
Parameter
No.
Function name
Monitor or data range
(Digital Operator)
Default
setting
Change
during
Run
Unit
Modbus
Address
(Hex)
Page

Omron JX Specifications

General

Enclosure Rating	IP20
Output Frequency	0 to 400 Hz
Protection	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit
Communication	RS-485
Frequency Range	0.1 to 400 Hz
Power Rating	0.4 to 15 kW
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +65°C
Humidity	5 to 95% RH (non-condensing)
Altitude	Up to 1000 m above sea level
Output Voltage	3-phase 200 to 240 VAC, 3-phase 380 to 480 VAC
Cooling Method	Fan cooling
