1287
CS-series Instruction Execution Times and Number of Steps Section 4-1
4-1-4 Timer and Counter Instructions
Note When a double-length operand is used, add 1 to the value shown in the length
column in the following table.
Instruction Mnemonic Code Length
(steps)
(See note.)
ON execution time (µs) Conditions
CPU-6@HCPU-4@HCPU-6@ CPU-4@
HUNDRED-
MS TIMER
TIM --- 3 0.56 0.88 0.37 0.42 ---
TIMX 550 3 0.56 0.88 --- --- ---
TEN-MS
TIMER
TIMH 015 3 0.88 1.14 0.37 0.42 ---
TIMHX 551 3 0.88 1.14 --- --- ---
ONE-MS
TIMER
TMHH 540 3 0.86 1.12 0.37 0.42 ---
TMHHX 552 3 0.86 1.12 --- --- ---
ACCUMULA-
TIVE TIMER
TTIM 087 3 16.1 17.0 21.4 21.4 ---
10.9 11.4 14.8 14.8 When resetting
8.5 8.7 10.7 10.7 When interlock-
ing
TTIMX 555 3 16.1 17.0 --- --- ---
10.9 11.4 --- --- When resetting
8.5 8.7 --- --- When interlock-
ing
LONG TIMER TIML 542 4 7.6 10.0 12.8 12.8 ---
6.2 6.5 7.8 7.8 When interlock-
ing
TIMLX 553 4 7.6 10.0 --- --- ---
6.2 6.5 --- --- When interlock-
ing
MULTI-OUT-
PUT TIMER
MTIM 543 4 20.9 23.3 26.0 26.0 ---
5.6 5.8 7.8 7.8 When resetting
MTIMX 554 4 20.9 23.3 --- --- ---
5.6 5.8 --- --- When resetting
COUNTER CNT --- 3 0.56 0.88 0.37 0.42 ---
CNTX 546 3 0.56 0.88 --- --- ---
REVERSIBLE
COUNTER
CNTR 012 3 16.9 19.0 20.9 20.9 ---
CNTRX 548 3 16.9 19.0 --- --- ---
RESET
TIMER/
COUNTER
CNR 545 3 9.9 10.6 13.9 13.9 When resetting
1 word
4.16 ms 4.16 ms 5.42 ms 5.42 ms When resetting
1,000 words
CNRX 547 3 9.9 10.6 --- --- When resetting
1 word
4.16 ms 4.16 ms --- --- When resetting
1,000 words
