1290
CS-series Instruction Execution Times and Number of Steps Section 4-1
4-1-6 Data Movement Instructions
Note When a double-length operand is used, add 1 to the value shown in the length
column in the following table.
Instruction Mnemonic Code Length
(steps)
(See note.)
ON execution time (µs) Conditions
CPU-6@HCPU-4@HCPU-6@ CPU-4@
MOVE MOV 021 3 0.18 0.20 0.25 0.29 ---
!MOV 021 7 +21.38 +21.40 +42.36 +42.36 Increase for CS
Series
+90.52 +90.52 +90.52 +90.52 Increase for
C200H
DOUBLE
MOVE
MOVL 498 3 0.32 0.34 0.42 0.50 ---
MOVE NOT MVN 022 3 0.18 0.20 0.25 0.29 ---
DOUBLE
MOVE NOT
MVNL 499 3 0.32 0.34 0.42 0.50 ---
MOVE BIT MOVB 082 4 0.24 0.34 7.5 7.5 ---
MOVE DIGIT MOVD 083 4 0.24 0.34 7.3 7.3 ---
MULTIPLE
BIT TRANS-
FER
XFRB 062 4 10.1 10.8 13.6 13.6 Transferring 1
bit
186.4 189.8 269.2 269.2 Transferring 255
bits
BLOCK
TRANSFER
XFER 070 4 0.36 0.44 11.2 11.2 Transferring 1
word
300.1 380.1 633.5 633.5 Transferring
1,000 words
BLOCK SET BSET 071 4 0.26 0.28 8.5 8.5 Setting 1 word
200.1 220.1 278.3 278.3 Setting 1,000
words
DATA
EXCHANGE
XCHG 073 3 0.40 0.56 0.5 0.7 ---
DOUBLE
DATA
EXCHANGE
XCGL 562 3 0.76 1.04 0.9 1.3 ---
SINGLE
WORD DIS-
TRIBUTE
DIST 080 4 5.1 5.4 7.0 7.0 ---
DATA COL-
LECT
COLL 081 4 5.1 5.3 7.1 7.1 ---
MOVE TO
REGISTER
MOVR 560 3 0.08 0.08 0.42 0.50 ---
MOVE TIMER/
COUNTER PV
TO REGIS-
TER
MOVRW 561 3 0.42 0.50 0.42 0.50 ---
