1293
CS-series Instruction Execution Times and Number of Steps Section 4-1
4-1-9 Symbol Math Instructions
Instruction Mnemonic Code Length
(steps)
(See note.)
ON execution time (µs) Conditions
CPU-6@HCPU-4@HCPU-6@ CPU-4@
SIGNED
BINARY
ADD WITH-
OUT
CARRY
+ 400 4 0.18 0.20 0.25 0.37 ---
DOUBLE
SIGNED
BINARY
ADD WITH-
OUT
CARRY
+L 401 4 0.32 0.34 0.42 0.54 ---
SIGNED
BINARY
ADD WITH
CARRY
+C 402 4 0.18 0.20 0.25 0.37 ---
DOUBLE
SIGNED
BINARY
ADD WITH
CARRY
+CL 403 4 0.32 0.34 0.42 0.54 ---
BCD ADD
WITHOUT
CARRY
+B 404 4 8.2 8.4 14.0 14.0 ---
DOUBLE
BCD ADD
WITHOUT
CARRY
+BL 405 4 13.3 14.5 19.0 19.0 ---
BCD ADD
WITH
CARRY
+BC 406 4 8.9 9.1 14.5 14.5 ---
DOUBLE
BCD ADD
WITH
CARRY
+BCL 407 4 13.8 15.0 19.6 19.6 ---
SIGNED
BINARY
SUBTRACT
WITHOUT
CARRY
– 410 4 0.18 0.20 0.25 0.37 ---
DOUBLE
SIGNED
BINARY
SUBTRACT
WITHOUT
CARRY
–L 411 4 0.32 0.34 0.42 0.54 ---
SIGNED
BINARY
SUBTRACT
WITH
CARRY
–C 412 4 0.18 0.20 0.25 0.37 ---
DOUBLE
SIGNED
BINARY
SUBTRACT
WITH
CARRY
–CL 413 4 0.32 0.34 0.42 0.54 ---
