Omron SYSMAC CJ - REFERENCE MANUAL 08-2008 - Page 1348

1308
CS-series Instruction Execution Times and Number of Steps Section 4-1
4-1-28 Other Instructions
Note When a double-length operand is used, add 1 to the value shown in the length
column in the following table.
4-1-29 Block Programming Instructions
Instruction Mnemonic Code Length
(steps)
(See note.)
ON execution time (µs) Conditions
CPU-6@HCPU-4@HCPU-6@ CPU-4@
SET CARRY STC 040 1 0.06 0.06 0.12 0.12 ---
CLEAR
CARRY
CLC 041 1 0.06 0.06 0.12 0.12 ---
SELECT EM
BANK
EMBC 281 2 14.0 15.1 15.1 15.1 ---
EXTEND
MAXIMUM
CYCLE
TIME
WDT 094 2 15.0 19.7 19.7 19.7 ---
SAVE CON-
DITION
FLAGS
CCS 282 1 8.6 12.5 --- --- ---
LOAD CON-
DITION
FLAGS
CCL 283 1 9.8 13.9 --- --- ---
CONVERT
ADDRESS
FROM CV
FRMCV 284 3 13.6 19.9 --- --- ---
CONVERT
ADDRESS
TO CV
TOCV 285 3 11.9 17.2 --- --- ---
DISABLE
PERIPH-
ERAL SER-
VICING
IOSP 287 --- 13.9 19.8 --- --- ---
ENABLE
PERIPH-
ERAL SER-
VICING
IORS 288 --- 63.6 92.3 --- --- ---
Instruction Mnemonic Code Length
(steps)
(See note.)
ON execution time (µs) Conditions
CPU-6@HCPU-4@HCPU-6@ CPU-4@
BLOCK
PROGRAM
BEGIN
BPRG 096 2 12.1 13.0 13.0 13.0 ---
BLOCK
PROGRAM
END
BEND 801 1 9.6 12.3 13.1 13.1 ---
BLOCK
PROGRAM
PAUS E
BPPS 811 2 10.6 12.3 14.9 14.9 ---
BLOCK
PROGRAM
RESTART
BPRS 812 2 5.1 5.6 8.3 8.3 ---
CONDI-
TIONAL
BLOCK
EXIT
(Execution
condition)
EXIT
806 1 10.0 11.3 12.9 12.9 EXIT condition
satisfied
4.0 4.9 7.3 7.3 EXIT condition
not satisfied
