1314
CJ-series Instruction Execution Times and Number of Steps Section 4-2
Note When a double-length operand is used, add 1 to the value shown in the length
column in the following table
4-2-2 Sequence Output Instructions
AND NOT AND
NOT
--- 1 0.016 0.02 0.04 0.08 0.10 0.10 ---
!AND
NOT
--- 2 +21.14 +21.14 +21.16 +21.16 +24.10 +28.07 Increase for immedi-
ate refresh
OR OR --- 1 0.016 0.02 0.04 0.08 0.10 0.10 ---
!OR --- 2 +21.14 +21.14 +21.16 +21.16 +24.10 +28.07 Increase for immedi-
ate refresh
OR NOT OR NOT --- 1 0.016 0.02 0.04 0.08 0.10 0.10 ---
!OR
NOT
--- 2 +21.14 +21.14 +21.16 +21.16 +24.10 +28.07 Increase for immedi-
ate refresh
AND LOAD AND LD --- 1 0.016 0.02 0.04 0.08 0.05 0.05 ---
OR LOAD OR LD --- 1 0.016 0.02 0.04 0.08 0.05 0.05 ---
NOT NOT 520 1 0.016 0.02 0.04 0.08 0.05 0.05 ---
CONDI-
TION ON
UP 521 3 0.24 0.3 0.42 0.54 0.50 0.50 ---
CONDI-
TION OFF
DOWN 522 4 0.24 0.3 0.42 0.54 0.50 0.50 ---
LOAD BIT
TEST
LD TST 350 4 0.11 0.14 0.24 0.37 0.35 0.35 ---
LOAD BIT
TEST NOT
LD
TSTN
351 4 0.11 0.14 0.24 0.37 0.35 0.35 ---
AND BIT
TEST NOT
AND
TSTN
351 4 0.11 0.14 0.24 0.37 0.35 0.35 ---
OR BIT
TEST
OR TST 350 4 0.11 0.14 0.24 0.37 0.35 0.35 ---
OR BIT
TEST NOT
OR
TSTN
351 4 0.11 0.14 0.24 0.37 0.35 0.35 ---
Instruction Mne-
monic
Code Length
(steps)
(See
note.)
ON execution time (µs) Conditions
CPU6@
H-R
CPU6@
H
CPU4@
H
CPU4@ CJ1M
exclud-
ing
CPU11/
21
CJ1M
CPU11/
21
OUTPUT OUT --- 1 0.016 0.02 0.04 0.21 0.35 0.35 ---
!OUT --- 2 +21.37 +21.37 +21.37 +21.37 +23.07 +28.60 Increase for immedi-
ate refresh
OUTPUT
NOT
OUT
NOT
--- 1 0.016 0.02 0.04 0.21 0.35 0.35 ---
!OUT
NOT
--- 2 +21.37 +21.37 +21.37 +21.37 +23.07 +28.60 Increase for immedi-
ate refresh
KEEP KEEP 11 1 0.048 0.06 0.08 0.29 0.40 0.40 ---
DIFFEREN-
TIATE UP
DIFU 13 2 0.21 0.24 0.40 0.54 0.50 0.50 ---
Instruction Mne-
monic
Code Length
(steps)
ON execution time (µs) Conditions
CPU6@
H-R
CPU6@
H
CPU4@
H
CPU4@ CJ1M
exclud-
ing
CPU11/
21
CJ1M
CPU11/
21
