CJ-series Instruction Execution Times and Number of Steps Section 4-2
Note 1. When a double-length operand is used, add 1 to the value shown in the
length column in the following table.
2. Supported only by CPU Units Ver. 2.0 or later.
4-2-6 Data Movement Instructions
UNSIGNED
BLOCK
COMPARE
BCMP 68 4 21.5 21.5 23.7 32.6 47.93 51.67 ---
EXPANDED
BLOCK
COMPARE
BCMP2 502 4 8.4 --- --- --- 13.20 19.33 Number of data
words: 1
313.0 --- --- --- 650.0 754.67 Number of data
words: 255
AREA
RANGE
COMPARE
ZCP 88 3 5.3 5.3 5.4 --- 11.53 12.43 ---
DOUBLE
AREA
RANGE
COMPARE
ZCPL 116 3 5.5 5.5 6.7 --- 11.28 11.90 ---
Instruction Mne-
monic
Code Length
(steps)
(See
note.)
ON execution time (µs) Conditions
CPU6
@H-R
CPU6
@H
CPU4
@H
CPU4
@
CJ1M
exclud-
ing
CPU11
/21
CJ1M
CPU11
/21
Instruction Mne-
monic
Code Length
(steps)
(See
note.)
ON execution time (µs) Conditions
CPU6@
H-R
CPU6@
H
CPU4@
H
CPU4@ CJ1M
exclud-
ing
CPU11/
21
CJ1M
CPU11/
21
MOVE MOV 21 3 0.14 0.18 0.20 0.29 0.30 0.30 ---
!MOV 21 7 21.38 21.38 21.40 42.36 +35.1 43.0 Increase for
immediate refresh
DOUBLE
MOVE
MOVL 498 3 0.26 0.32 0.34 0.50 0.60 0.60 ---
MOVE NOT MVN 22 3 0.14 0.18 0.20 0.29 0.35 0.35 ---
DOUBLE
MOVE NOT
MVNL 499 3 0.26 0.32 0.34 0.50 0.60 0.60 ---
MOVE BIT MOVB 82 4 0.19 0.24 0.34 7.5 0.50 0.50 ---
MOVE
DIGIT
MOVD 83 4 0.19 0.24 0.34 7.3 0.50 0.50 ---
MULTIPLE
BIT TRANS-
FER
XFRB 62 4 10.1 10.1 10.8 13.6 20.9 22.1 Transferring 1 bit
186.4 186.4 189.8 269.2 253.3 329.7 Transferring 255
bits
BLOCK
TRANSFER
XFER 70 4 0.29 0.36 0.44 11.2 0.8 0.8 Transferring 1
word
240.1 300.1 380.1 633.5 650.2 650.2 Transferring 1,000
words
BLOCK SET BSET 71 4 0.21 0.26 0.28 8.5 0.55 0.55 Setting 1 word
142.2 200.1 220.1 278.3 400.2 400.2 Setting 1,000
words
DATA
EXCHANGE
XCHG 73 3 0.32 0.40 0.56 0.7 0.80 0.80 ---
