Omron SYSMAC CJ - REFERENCE MANUAL 08-2008

138
List of Instructions by Function Code Section 2-4
344 LD <= DT LD TIME LESS THAN
OR EQUAL
--- --- --- 297
344 OR <= DT OR TIME LESS THAN
OR EQUAL
--- --- --- 297
345 AND > DT AND TIME GREATER
THAN
--- --- --- 297
345 LD > DT LOAD TIME GREATER
THAN
--- --- --- 297
345 OR > DT OR TIME GREATER
THAN
--- --- --- 297
346 AND >= DT AND TIME GREATER
THAN OR EQUAL
--- --- --- 297
346 LD >= DT LOAD TIME GREATER
THAN OR EQUAL
--- --- --- 297
346 OR >= DT OR TIME GREATER
THAN OR EQUAL
--- --- --- 297
350 AND TST AND BIT TEST --- --- --- 182
350 LD TST LOAD BIT TEST --- --- --- 182
350 OR TST OR BIT TEST --- --- --- 182
351 AND TSTN AND BIT TEST NOT --- --- --- 182
351 LD TSTN LOAD BIT TEST NOT --- --- --- 182
351 OR TSTN OR BIT TEST NOT --- --- --- 182
400 + SIGNED BINARY ADD
WITHOUT CARRY
@+ --- --- 426
401 +L DOUBLE SIGNED
BINARY ADD
WITHOUT CARRY
@+L --- --- 428
402 +C SIGNED BINARY ADD
WITH CARRY
@+C --- --- 430
403 +CL DOUBLE SIGNED
BINARY ADD WITH
CARRY
@+CL --- --- 432
404 +B BCD ADD WITHOUT
CARRY
@+B --- --- 437
405 +BL DOUBLE BCD ADD
WITHOUT CARRY
@+BL --- --- 435
406 +BC BCD ADD WITH
CARRY
@+BC --- --- 437
407 +BCL DOUBLE BCD ADD
WITH CARRY
@+BCL --- --- 439
410 – SIGNED BINARY
SUBTRACT
WITHOUT CARRY
@– --- --- 440
411 –L DOUBLE SIGNED
BINARY SUBTRACT
WITHOUT CARRY
@–L --- --- 442
412 –C SIGNED BINARY
SUBTRACT WITH
CARRY
@–C --- --- 446
413 –CL DOUBLE SIGNED
BINARY SUBTRACT
WITH CARRY
@–CL --- --- 448
414 –B BCD SUBTRACT
WITHOUT CARRY
@–B --- --- 451
415 –BL DOUBLE BCD
SUBTRACT
WITHOUT CARRY
@–BL --- --- 452
416 –BC BCD SUBTRACT
WITH CARRY
@–BC --- --- 456
417 –BCL DOUBLE BCD
SUBTRACT WITH
CARRY
@–BCL --- --- 457
Function code Mnemonic Instruction Upward
Differentiation
Downward
Differentiation
Immediate
Refreshing
Specification
Page
