Omron SYSMAC CJ - REFERENCE MANUAL 08-2008

139
List of Instructions by Function Code Section 2-4
420 * SIGNED BINARY
MULTIPLY
@* --- --- 459
421 *L DOUBLE SIGNED
BINARY MULTIPLY
@*L --- --- 461
422 *U UNSIGNED BINARY
MULTIPLY
@*U --- --- 463
423 *UL DOUBLE UNSIGNED
BINARY MULTIPLY
@*UL --- --- 465
424 *B BCD MULTIPLY @*B --- --- 467
425 *BL DOUBLE BCD
MULTIPLY
@*BL --- --- 469
430 / SIGNED BINARY
DIVIDE
@/ --- --- 471
431 /L DOUBLE SIGNED
BINARY DIVIDE
@/L --- --- 473
432 /U UNSIGNED BINARY
DIVIDE
@/U --- --- 475
433 /UL DOUBLE UNSIGNED
BINARY DIVIDE
@/UL --- --- 477
434 /B BCD DIVIDE @/B --- --- 479
435 /BL DOUBLE BCD DIVIDE @/BL --- --- 481
448 FSTR FLOATING POINT TO
ASCII
@FSTR --- --- 640
449 FVAL ASCII TO FLOATING
POINT
@FVAL --- --- 645
450 FIX FLOATING TO 16-BIT @FIX --- --- 594
451 FIXL FLOATING TO 32-BIT @FIXL --- --- 596
452 FLT 16-BIT TO FLOATING @FLT --- --- 597
453 FLTL 32-BIT TO FLOATING @FLTL --- --- 599
454 +F FLOATING-POINT
ADD
@+F --- --- 601
455 –F FLOATING-POINT
SUBTRACT
@–F --- --- 603
456 *F FLOATING-POINT
MULTIPLY
@*F --- --- 605
457 /F FLOATING-POINT
DIVIDE
@/F --- --- 607
458 RAD DEGREES TO
RADIANS
@RAD --- --- 633
459 DEG RADIANS-TO
DEGREES
@DEG --- --- 610
460 SIN SINE @SIN --- --- 612
461 COS COSINE @COS --- --- 615
462 TAN TANGENT @TAN --- --- 619
463 ASIN ARC SINE @ASIN --- --- 623
464 ACOS ARC COSINE @ACOS --- --- 625
465 ATAN ARC TANGENT @ATAN --- --- 627
466 SQRT SQUARE ROOT @SQRT --- --- 629
467 EXP EXPONENT @EXP --- --- 631
468 LOG LOGARITHM @LOG --- --- 633
469 MOVF MOVE FLOATING-
POINT (SINGLE)
@MOVF --- --- 649
470 BINS SIGNED BCD TO
BINARY
@BINS --- --- 517
471 BCDS SIGNED BINARY TO
BCD
@BCDS --- --- 523
472 BISL DOUBLE SIGNED
BCD TO BINARY
@BISL --- --- 520
Function code Mnemonic Instruction Upward
Differentiation
Downward
Differentiation
Immediate
Refreshing
Specification
Page
