Omron SYSMAC CJ - REFERENCE MANUAL 08-2008 User Manual

xxiii
About this Manual:
This manual describes the ladder diagram programming instructions of the CPU Units for CS/CJ-
series Programmable Controllers (PLCs). The CS Series, CJ Series and NSJ Series are subdivided as
shown in the following figure.
NSJ-series Controller Notation
For information in this manual on the Controller Section of NSJ-series Controllers, refer to the informa-
tion of the equivalent CJ-series PLC. The following models are equivalent.
NSJ-series Controllers Equivalent CJ-series CPU Unit
NSJ@-TQ@@(B)-G5D CJ1G-CPU45H CPU Unit with unit version 3.0
NSJ@-TQ@@(B)-M3D CJ1G-CPU45H CPU Unit with unit version 3.0 (See note.)
Note: The following points differ between the NSJ@-TQ@@(B)-M3D and the CJ1G-CPU45H.
Please read this manual and all related manuals listed in the table on the next page and be sure you
understand information provided before attempting to program or use CS/CJ-series CPU Units in a
PLC System.
Item CJ-series CPU Unit
CJ1G-CPU45H
Controller Section in
NSJ@-@@@@(B)-M3D
I/O capacity 1280 points 640 points
Program capacity 60 Ksteps 20 Ksteps
No. of Expansion Racks 3 max. 1 max.
EM Area 32 Kwords x 3 banks
E0_00000 to E2_32767
None
Function blocks Max. No. of definitions 1024 128
Max. No. of instances 2048 256
Capacity in built-in
file memory
FB program memory 1024 KB 256 KB
Variable tables 128 KB 64K KB
CS1H-CPU@@H
CS1G-CPU@@H
CS1-H CPU Units
CS Series
CS1 CPU Units
CS1H-CPU@@(-V1)
CS1G-CPU@@(-V1)
CS1D CPU Units
CS1D CPU Units for
Duplex Systems
CS1D-CPU@@H
CS1D CPU Units for
Simplex Systems
CS1D-CPU@@S
CS1D Process-control CPU Units
CS1D-CPU@@P
CS-series Basic I/O Units
CS-series Special I/O Units
CS-series CPU Bus Units
CS-series Power Supply Units
Note: A special Power Supply Unit must
be used for CS1D CPU Units.
CJ-series Power Supply Units
CJ-series CPU Bus Units
CJ-series Special I/O Units
CJ-series Basic I/O Units
CJ1G-CPU@@
CJ1 CPU Units
CJ1M CPU Units
CJ1M-CPU@@
CJ1H-CPU@@H-R
CJ1H-CPU@@H
CJ1G-CPU@@H
CJ1G -CPU@@P
(Loop-control CPU Units)
CJ1-H CPU Units
CJ Series
NSJ Series
NSJ Controllers
NSJ5-TQ@@(B)-G5D
NSJ5-SQ@@(B)-G5D
NSJ8-TV@@(B)-G5D
NSJ10-TV@@(B)-G5D
NSJ12-TS@@(B)-G5D
NSJ Controllers
NSJ5-TQ@@(B)-M3D
NSJ5-SQ@@(B)-M3D
NSJ8-TV@@(B)-M3D
NSJ-series Expansion Units
CJ2H-CPU@@-@@@
CJ2 CPU Units
