Sequence Control Instructions Section 3-5
Examples When CIO 000000 is OFF in the following example, all outputs between
IL(002) and ILC(003) are interlocked. When CIO 000000 is ON in the follow-
ing example, the instructions between IL(002) and ILC(003) are executed nor-
mally.
CIO 000000
ON
CIO 000000
OFF
OFF
OFF
Reset
Retained
Retained
Normal
execution
Outputs
interlocked
