Conversion Instructions Section 3-12
N: Bit Number
Specifies the bit number (0000 to 000F or &0 to &15) to be overwritten by the
source word.
Operand Specifications
Area S D N
CIO Area CIO 0000 to
CIO 6143
CIO 0000 to
CIO 6128
CIO 0000 to
CIO 6143
Work Area W000 to W511 W000 to W496 W000 to W511
Holding Bit Area H000 to H511 H000 to H496 H000 to H511
Auxiliary Bit Area A000 to A959 A448 to A944 A000 to A959
Timer Area T0000 to T4095 T0000 to T4080 T0000 to T4095
Counter Area C0000 to C4095 C0000 to C4080 C0000 to C4095
DM Area D00000 to
D32767
D00000 to
D32752
D00000 to
D32767
EM Area without bank E00000 to
E32767
E00000 to
E32752
E00000 to
E32767
EM Area with bank En_00000 to
En_32767
(n = 0 to C)
En_00000 to
En_32752
(n = 0 to C)
En_00000 to
En_32767
(n = 0 to C)
Indirect DM/EM
addresses in binary
@ D00000 to @ D32767
@ E00000 to @ E32767
@ En_00000 to @ En_32767
(n = 0 to C)
Indirect DM/EM
addresses in BCD
*D00000 to *D32767
*E00000 to *E32767
*En_00000 to *En_32767
(n = 0 to C)
Constants #0000 to #FFFF
(binary)
--- #0000 to #000F
(binary) or &0 to
&15
Data Registers DR0 to DR15 --- DR0 to DR15
Index Registers ---
Indirect addressing
using Index Registers
,IR0 to ,IR15
–2048 to +2047 ,IR0 to –2048 to +2047 ,IR15
DR0 to DR15, IR0 to IR15
,IR0+(++) to ,IR15+(++)
,–(– –)IR0 to, –(– –)IR15
