Conversion Instructions Section 3-12
Description COLM(064) copies the 16 bits from S to the 16 bits with bit number N in the
16-word range D to D+15. Bit m of S is copied to bit N of D+m, i.e., bit 00 of S
is copied to bit N of D and bit 15 of S is copied to bit N of D+15.
Flags
Example When CIO 000000 is ON in the following example, COLM(064) copies the 16
bits in D00200 (bits 00 through 15) to bit 5 in D00100 through D00115.
0
0 0 0 0 1 1 1 0 001 0 0 0 01
15 00
D
1 1 0 1 0 0 1 0 011 1 0 0 01
D+1
0 0 0 1 1 0 1 1 001 0 0 1 11
D+2
.
.
.
.
.
.
.
.
.
.
0 1 1 1 0 0 0 1 100 0 1 0 10
D+15
1 0 0 0 0 0 1 1 000 0 0 1 11
D+3
0 1 1
S
1
15 00
. . . . . .
.
.
.
Bit Bit
Bi
Bit Bit
Name Label Operation
Error Flag ER ON if N is not within the specified range of 0000 to 000F.
OFF in all other cases.
Equals Flag = ON if bit N is 0 in all 16 words D to D+15 after execution.
OFF in all other cases.
S: D00200
D:
to
to
