Instruction Classifications by Function Section 2-1
Symbol
math
instructions
Binary add + SIGNED
BINARY ADD
WITHOUT
CARRY
+L DOUBLE
SIGNED
BINARY ADD
WITHOUT
CARRY
+C SIGNED
BINARY ADD
WITH CARRY
+CL DOUBLE
SIGNED
BINARY ADD
WITH CARRY
--- --- --- ---
BCD add +B BCD ADD
WITHOUT
CARRY
+BL DOUBLE BCD
ADD
WITHOUT
CARRY
+BC BCD ADD
WITH CARRY
+BCL DOUBLE BCD
ADD WITH
CARRY
--- --- --- ---
Binary subtract – SIGNED
BINARY SUB-
TRACT
WITHOUT
CARRY
–L DOUBLE
SIGNED
BINARY
SUBTRACT
WITHOUT
CARRY
–C SIGNED
BINARY
SUBTRACT
WITH CARRY
–CL DOUBLE
SIGNED
BINARY WITH
CARRY
--- --- --- ---
BCD subtract –B BCD
SUBTRACT
WITHOUT
CARRY
–BL DOUBLE BCD
SUBTRACT
WITHOUT
CARRY
–BC BCD
SUBTRACT
WITH CARRY
–BCL DOUBLE BCD
SUBTRACT
WITH CARRY
--- --- --- ---
Binary multiply * SIGNED
BINARY
MULTIPLY
*LDOUBLE
SIGNED
BINARY
MULTIPLY
*U UNSIGNED
BINARY
MULTIPLY
*UL DOUBLE
UNSIGNED
BINARY
MULTIPLY
--- --- --- ---
BCD multiply *B BCD
MULTIPLY
*BL DOUBLE BCD
MULTIPLY
--- ---
Binary divide / SIGNED
BINARY
DIVIDE
/L DOUBLE
SIGNED
BINARY
DIVIDE
/U UNSIGNED
BINARY
DIVIDE
/UL DOUBLE
UNSIGNED
BINARY
DIVIDE
--- --- --- ---
BCD divide /B BCD DIVIDE /BL DOUBLE BCD
DIVIDE
--- ---
Classifica-
tion
Sub-class Mnemonic Instruction Mnemonic Instruction Mnemonic Instruction
