Instruction Classifications by Function Section 2-1
Conversion
instructions
BCD-binary con-
versions
BIN BCD TO
BINARY
BINL DOUBLE BCD
TO DOUBLE
BINARY
BCD BINARY TO
BCD
BCDL DOUBLE
BINARY TO
DOUBLE BCD
NEG 2’S COMPLE-
MENT
NEGL DOUBLE 2’S
COMPLE-
MENT
SIGN 16-BIT TO
32-BIT
SIGNED
BINARY
--- --- --- ---
Decoder/ encoder MLPX DATA
DECODER
DMPX DATA
ENCODER
--- ---
ASCII-hexadecimal
conversions
ASC ASCII CON-
VERT
HEX ASCII TO HEX --- ---
Line-column con-
versions
LINE COLUMN TO
LINE
COLM LINE TO
COLUMN
--- ---
Signed binary-BCD
conversions
BINS SIGNED BCD
TO BINARY
BISL DOUBLE
SIGNED BCD
TO BINARY
BCDS SIGNED
BINARY TO
BCD
BDSL DOUBLE
SIGNED
BINARY TO
BCD
GRY
(See note 1.)
GRAY CODE
CONVER-
SION
--- ---
Number-ASCII con-
versions
STR4 FOUR-DIGIT
NUMBER TO
ASCII
STR8 EIGHT-DIGIT
NUMBER TO
ASCII
STR16 SIXTEEN-
DIGIT NUM-
BER TO ASCII
NUM4 ASCII TO
FOUR-DIGIT
NUMBER
NUM8 ASCII TO
EIGHT-DIGIT
NUMBER
NUM16 ASCII TO SIX-
TEEN-DIGIT
NUMBER
Logic
instructions
Logical AND/OR ANDW LOGICAL
AND
ANDL DOUBLE
LOGICAL
AND
ORW LOGICAL OR
ORWL DOUBLE
LOGICAL OR
XORW EXCLUSIVE
OR
XORL DOUBLE
EXCLUSIVE
OR
XNRW EXCLUSIVE
NOR
XNRL DOUBLE
EXCLUSIVE
NOR
--- ---
Complement COM COMPLE-
MENT
COML DOUBLE
COMPLE-
MENT
--- ---
Special
math
instructions
--- ROTB BINARY
ROOT
ROOT BCD SQUARE
ROOT
APR ARITHMETIC
PROCESS
FDIV FLOATING
POINT
DIVIDE
BCNT BIT
COUNTER
--- ---
Classifica-
tion
Sub-class Mnemonic Instruction Mnemonic Instruction Mnemonic Instruction
