Install a Processor
Caution - Do not press down on the processor. Irreparable damage to the processor or
motherboard might occur from excessive downward pressure. Do not forcibly seat the processor
into the socket. Excessive downward pressure might damage the socket pins.
7.
Swing the processor ILM assembly load plate into the closed position [2].
Ensure that the load plate sits flat around the periphery of the processor.
Servicing Components That Require Server Power-Off 109
