Servicing SAS Cables
Note - IMPORTANT: When the disk backplane is replaced, the key identity properties (KIP)
of the disk backplane is programmed by Oracle ILOM to contain the same KIP as the other
quorum member components. If you have removed other quorum member components,
you might need to manually program the product serial number (PSN) into the new disk
backplane. For more information, refer to “FRU Key Identity Properties (KIP) Automated
Update” on page 49.
Related Information
■
“Remove the Storage Drive Backplane” on page 112
Servicing SAS Cables
Caution - The system supplies power to the cables even when the server is powered off.
To avoid personal injury or damage to the server, you must disconnect power cords before
servicing the cables.
This section covers the following topics:
■
“Remove SAS Storage Drive Cables” on page 118
■
“Install SAS Storage Drive Cables” on page 121
Related Information
■
“Servicing Storage Drives and Rear Drives” on page 61
■
“Servicing the Storage Drive Backplanes” on page 112
Remove SAS Storage Drive Cables
1.
Prepare the server for service.
a.
Power off the server and disconnect the power cords from the power
supplies.
See “Powering Down the Server” on page 51.
118 Oracle Exadata Storage Server X5-2 High Capacity Service Manual • January 2018
