Remove the Left LED Indicator Module
■
“Remove the Right LED/USB Indicator Module” on page 138
■
“Install the Right LED/USB Indicator Module” on page 141
Related Information
■
“Troubleshooting Using the Server Front and Rear Panel Status Indicators ” on page 26
Remove the Left LED Indicator Module
1.
Prepare the server for service.
a.
Power off the server and disconnect the power cords from the power
supplies.
See “Powering Down the Server” on page 51.
b.
Extend the server into the maintenance position.
See “Extend the Server to the Maintenance Position” on page 55.
c.
Attach an antistatic wrist strap to your wrist, and then to a metal area on the
chassis.
See “Take Antistatic Measures” on page 57.
d.
Remove the server top cover.
See “Remove the Server Top Cover” on page 58.
2.
Remove the server fan assembly door.
See “Remove the Fan Assembly Door From the Server” on page 59.
Servicing Components That Require Server Power-Off 131
