Install SAS Storage Drive Cables
Related Information
■
“Remove the Sun Storage 12 Gb/s SAS PCIe RAID HBA Card” on page 124
■
“Install SAS Storage Drive Cables” on page 121
Install SAS Storage Drive Cables
1.
Install SAS storage drive cables.
a.
Install the SAS cables between the front storage drive backplane and the
Oracle Storage 12 Gb/s SAS PCIe RAID HBA card in PCIe slot 6 [1].
Route the SAS cable bundle through the chassis mid-wall and along the left side of the
chassis.
b.
(Optional) Install the cables between the front storage drive backplane and
the rear-mounted storage drive backplane [2].
Route the SAS cable bundle through the chassis mid-wall and along the right side of the
chassis.
2.
Reconnect the SAS cables.
a.
To reconnect the SAS cables between the front storage drive backplane and
the Oracle Storage 12 Gb/s SAS PCIe RAID HBA card, plug each cable into
its SAS connector until you hear an audible click [1].
See also “Install the Oracle Storage 12 Gb/s SAS PCIe RAID HBA Card” on page 127.
Use the following table to ensure proper SAS cable connections:
System Disk
Configuration
Disk Backplane
Ports
HBA Port Cable Part
Number
J302 (Upper)Twelve storage drives
J301 (Lower)
J5A1 7091185
b.
(Optional) To reconnect the SAS cables between the front storage drive
backplane and the rear storage drive backplane, plug each cable into its
SAS connector until you hear an audible click [2].
Attach the SAS cable to connector (J300) on the front storage drive backplane and to SAS
connectors (RHDD0 and RHDD1) on the rear storage drive backplane.
Servicing Components That Require Server Power-Off 121
