Install the Oracle Storage 12 Gb/s SAS PCIe RAID HBA Card
Related Information
■
“Install the Oracle Storage 12 Gb/s SAS PCIe RAID HBA Card” on page 127
Install the Oracle Storage 12 Gb/s SAS PCIe RAID
HBA Card
1.
Unpack the replacement Oracle Storage 12 Gb/s SAS PCIe RAID HBA card and
super capacitor, and place them on an antistatic mat.
2.
Swivel the air baffle into the upright position and install the super capacitor
cable along the left sidewall of the chassis.
3.
Connect the super capacitor cable to the Oracle Storage 12 Gb/s SAS PCIe RAID
HBA, and then reconnect the SAS cables that you unplugged during the removal
procedure [1].
Servicing Components That Require Server Power-Off 127
