BIOS Advanced Menu Selections
Setup Options Options Defaults Description
press +/- keys to move the
attempt up/down in the
attempt order list.
BIOS Advanced Menu Ethernet Controller Options
The following table describes the BIOS Advanced Menu Ethernet controller options:
TABLE 29
BIOS Advanced Menu Ethernet Controller Options
Setup Options Options Defaults Description
Port Configuration Menu
NIC configuration Use to configure the
network device port.
Link Speed (R/O) Supported port speeds/
Auto Negotiate
NA Specifies the port speed
used for the selected boot
protocol.
Note - This option is not
supported.
Wake on LAN Disable/Enabled NA Enable or disable wake on
LAN.
Note - This option is not
supported.
Blink LEDs 0/1/2/3 0 Use to identify the
physical network port by
blinking the associated
LED.
Port Configuration
Information
Displays and specifies
the port settings for the
network device.
UEFI Driver (R/O) NA NA Identifies the UEFI driver.
Adapter PBA (R/O) NA NA Product board adapter
(PBA) number. You can
use the Intel Network
Adapter PBA number to
search for the adapter's
model number. The PBA
number is a nine digit
number that is the last part
of the adapter board serial
number. The PBA number
is presented in this format:
xxxxxxx-xxx, for example,
C80222-001.
