Install the Storage Drive Backplane
Install the Storage Drive Backplane
1.
Lower the storage drive backplane into the server, and position it to engage the
standoff hooks [1].
2.
Using a No. 2 Phillips screwdriver, install and tighten the right-side spring-
mounted screw to secure the storage drive backplane to the chassis [2].
116 Oracle Exadata Storage Server X5-2 High Capacity Service Manual • January 2018
