Identifying the Server Ports
These sections describe the pinouts of the server connectors.
Description Links
Review the Gigabit Ethernet ports. “Gigabit Ethernet Ports” on page 169
Review the network management ports. “Network Management Port” on page 170
Review the serial management ports. “Serial Management Port” on page 171
Review the video connectors. “Video Connector” on page 173
Review the USB ports. “USB Ports” on page 174
Related Information
■
“About the Oracle Exadata Storage Server X5-2 High Capacity” on page 13
Gigabit Ethernet Ports
The server has four auto-negotiating 100/1000/10GBASE-T Gigabit Ethernet (GbE) system
domain ports. All four Ethernet ports use a standard RJ-45 connector. The transfer rates are
shown in the following table.
TABLE 8
Ethernet Port Transfer Rates
Connection Type IEEE Terminology Transfer Rate
Fast Ethernet 100BASE-T 100 Mbps
Gigabit Ethernet 1000BASE-T 1,000 Mbps
10 Gigabit Ethernet 10GBASE-T 10,000 Mbps
The following figure and table describe the 10-GbE port pin signals.
Identifying the Server Ports 169
