Monitoring System Components
Related Information
■
“System Chassis Components” on page 231
■
“Cooling Unit Components” on page 233
■
“Memory Device Components” on page 235
■
“Power Unit Components” on page 236
■
“Processor Components” on page 237
■
“System Board Components” on page 237
■
“System Firmware Components” on page 239
■
“Hard Disk Drive Components” on page 239
Memory Device Components
The following table lists the memory device components.
Component Name (Oracle ILOM CLI
Targets)
IPMI Type Description Values (if applicable)
/SYS/MB/P[0-x]/D[0-11] FRU Host CPU DIMM
FRU
/SYS/MB/P[0-x]/D[0-11]/PRSNT Discrete
sensor
Host CPU DIMM is
present.
01h-ENTITY_ABSENT
02h-ENTITY_PRESENT
/SYS/MB/P[0-x]/D[0-11]/SERVICE Indicator Host CPU DIMM
Service Required
LED
Color: Amber
Location: Mainboard
Off: Normal
On: DIMM was diagnosed as
faulty.
Related Information
■
“System Chassis Components” on page 231
■
“Cooling Unit Components” on page 233
■
“Disk Backplane Components” on page 234
■
“Power Unit Components” on page 236
■
“Processor Components” on page 237
■
“System Board Components” on page 237
■
“System Firmware Components” on page 239
Monitoring Components and Identifying SNMP Messages 235
