Oracle EXADATA X5-2 - Return Server to Normal Rack Position

Return the Server to the Normal Rack Position
Related Information
■
“Remove the Server From the Rack” on page 56
■
“Reconnect Power and Data Cables” on page 167
Return the Server to the Normal Rack Position
If the server is in the extended maintenance position, use this procedure to return the server to
the normal rack position.
1.
Push the server back into the rack, as described in the following steps.
a.
Simultaneously pull and hold the two green release tabs (one on each side
of the slide rails on the server) toward the front of the server while you push
the server into the rack.
As you push the server into the rack, verify that the cable management arm (CMA) retracts
without binding.
Returning the Server to Operation 165
