Monitoring System Components
For further information about administering open problems that are detected and reported by
Oracle ILOM, refer to “Administering Open Problems” in the Oracle ILOM Administrator's
Guide for Configuration and Maintenance Firmware Release 3.2.x in the Oracle Integrated
Lights Out Manager (ILOM) 3.2 Documentation Library at http://www.oracle.com/goto/
ilom/docs.
Related Information
■
Oracle Integrated Lights Out Manager (ILOM) 3.2 Documentation Library at: http://www.
oracle.com/goto/ilom/docs
Monitoring System Components
The tables in this section identify the system components and describe the naming conventions
applied to the components of the Oracle Exadata Storage Server X5-2 High Capacity.
Each section corresponds to an IPMI entity ID and lists sensors, indicators, and field-
replaceable units (FRUs) related to that entity. The tables contain the following fields:
■
Component Name – Shows the user-visible component name used in management
interfaces to refer to a specific sensor, indicator, or FRU. The IPMI name is a shortened
form of the component name, and is indicated by the boldface portion of the component
name.
■
IPMI Type – Indicates the type of sensor, indicator, or FRU represented.
■
Description – Describes the particular component name reference.
■
Values – Defines the states of the sensor, indicator, or FRU entity, and any specific units or
values that are expected, if applicable.
Note - Some component names are hidden in the Oracle ILOM user interfaces. These names
are marked as hidden in the tables. Further, as of Oracle ILOM 3.1, the Oracle ILOM 3.0 legacy
targets /SYS and /STORAGE have been replaced by /System. Even though these legacy targets
might be hidden, you can still use them to issue commands. For information on legacy targets,
see the ILOM 3.1 Documentation Library at http://www.oracle.com/goto/ilom/docs.
This section includes information for the following server components:
■
“System Chassis Components” on page 231
■
“Cooling Unit Components” on page 233
230 Oracle Exadata Storage Server X5-2 High Capacity Service Manual • January 2018
