Monitoring System Components
■
“Disk Backplane Components” on page 234
■
“Memory Device Components” on page 235
■
“Power Unit Components” on page 236
■
“Processor Components” on page 237
■
“System Board Components” on page 237
■
“System Firmware Components” on page 239
■
“Hard Disk Drive Components” on page 239
Cooling Unit Components
The system has 3.5-inch fan modules with two fans in each module. The following table lists
the system cooling unit components.
Component Name (Oracle ILOM
CLI Targets)
IPMI Type Description Values (if applicable)
/SYS/MB/FM[0-3] FRU Fan module FRU
/SYS/MB/FM[0-3]/F[0-x] FRU Individual fan
/SYS/MB/FM[0-3]/PRSNT Discrete
sensor
Fan module is present. 01h-ENTITY_ABSENT
02h-ENTITY_PRESENT
/SYS/MB/FM[0-3]/F[0-x]/TACH Threshold
sensor
Fan module fan speed RPM
/SYS/MB/FM[0-3]/SERVICE Indicator Fan Service Required LED Color: Amber
Location: Mainboard
Off: Normal
On: Fan module was
diagnosed as faulty.
Related Information
■
“System Chassis Components” on page 231
■
“Disk Backplane Components” on page 234
■
“Memory Device Components” on page 235
■
“Power Unit Components” on page 236
■
“Processor Components” on page 237
■
“System Board Components” on page 237
■
“System Firmware Components” on page 239
Monitoring Components and Identifying SNMP Messages 233
