Troubleshoot Hardware Faults Using the Oracle ILOM Web Interface
Status
Indicator
Name
Icon Color State and Meaning
■ STEADY ON – Normal operation. Input AC power and DC
output voltage are within specification.
Service
Required
Amber ■ OFF – Normal operation. No service action is required.
■ STEADY ON – The power supply (PS) has detected a PS fan
failure, PS overtemperature, PS over current, or PS over or under
voltage.
Network Management Port Status Indicators
The server has one 10/100/1000BASE-T Ethernet management domain interface, labeled NET
MGT. There are two status indicators (LEDs) on this port. These indicators are visible from the
rear of the server.
TABLE 5
Network Management Port Status Indicators
Status
Indicator
Name
Location Color State and Meaning
Activity Top right Green ■ ON – Link up.
■ OFF – No link or down link.
■ FLASHING – Packet activity.
Link speed Top left Green ■ Green ON – 1000BASE-T link.
■ OFF – 10/100BASE-T link.
Ethernet Ports Status Indicators
The server has four Gigabit Ethernet ports (NET 3, NET 2, NET 1, and NET 0). There are two
status indicators on each port. These indicators (LEDs) are visible from the rear of the server.
TABLE 6
Gigabit Ethernet Port Status Indicators
Status
Indicator Name
Location Color State and Meaning
Activity Top left Green ■ ON – No function.
■ OFF – No activity.
■ FLASHING – Packet activity.
Link speed Top right Bicolored: Amber/
Green
■ OFF – 100BASE-T link.
■ Amber ON – 1000BASE-T link.
■ Green ON – 10GBBASE-T link.
■ FLASHING – No function.
30 Oracle Exadata Storage Server X5-2 High Capacity Service Manual • January 2018
