Monitoring System Components
System Firmware Components
The following table lists the system firmware components.
Component Name
(Oracle ILOM CLI Target)
IPMI Type Description
/SYS/MB/BIOS FRU BIOS FRU
/SYS/MB/CPLD FRU Mainboard CPLD/FPGA firmware
Related Information
■
“System Chassis Components” on page 231
■
“Cooling Unit Components” on page 233
■
“Disk Backplane Components” on page 234
■
“Memory Device Components” on page 235
■
“Power Unit Components” on page 236
■
“Processor Components” on page 237
■
“System Board Components” on page 237
■
“Hard Disk Drive Components” on page 239
Hard Disk Drive Components
The following table lists the hard disk drive (HDD) components.
Component Name (Oracle ILOM
CLI Targets)
IPMI Type Description Values (if applicable)
/SYS/MB/RHDD[0-1] FRU Rear hard disk drive FRU From host
/SYS/MB/RHDD[0-1]/PRSNT Discrete
sensor
Rear hard disk drive presence 01h-ENTITY_PRESENT,
02h-ENTITY_ABSENT
/SYS/MB/RHDD[0-1]/SERVICE Indicator Rear hard disk drive Service
Required LED
Color: Amber
Location: Rear HDD
Off: Normal
On: Hard disk drive (HDD)
was diagnosed as faulty.
Monitoring Components and Identifying SNMP Messages 239
