About Controls and Connectors
About Controls and Connectors
The following section describe the controls, indicators, connectors, and drives located on the
front and rear panels.
■
“Front Panel Components” on page 14
■
“Rear Panel Components and Cable Connections” on page 15
Related Information
■
“About System Components” on page 16
■
“Illustrated Parts Breakdown” on page 16
■
“Troubleshooting Using the Server Front and Rear Panel Status Indicators ” on page 26
Front Panel Components
Figure
Legend
Description
1 Locator LED/Locator button: white
14 Oracle Exadata Storage Server X5-2 High Capacity Service Manual • January 2018
