Extend the Server to the Maintenance Position
Extend the Server to the Maintenance Position
The following components can be serviced with the server in the maintenance position:
■
Storage drives
■
Fan modules
■
Power supplies
■
DVD drive
■
DDR4 DIMMs
■
PCIe cards and cables
■
SAS cables
■
NVMe cables
■
Internal USB drives
■
System battery
■
Processors
■
Disk backplanes
■
Front indicator modules
■
Motherboard
1.
To prevent the rack from tipping forward when the server is extended, extend all
rack anti-tilt devices.
For instructions for stabilizing the rack, refer to “Stabilize the Rack for Installation” in Oracle
Exadata Storage Server X5-2 High Capacity Installation Guide.
2.
Verify that no cables will be damaged or will interfere when the server is
extended.
Although the cable management arm (CMA) that is supplied with the server is hinged to
accommodate extending the server, you should ensure that all cables and cords are free from
obstruction by other devices.
3.
From the front of the server, open and hold the left and right release latch covers
in the open position.
When in an open position, the release latch covers engage the slide-rail release latches [1].
Preparing for Service 55
