Install a DIMM
Install a DIMM
1.
Unpack the replacement DDR4 DIMM and place it on an antistatic mat.
2.
Ensure that the replacement DDR4 DIMM matches the size of the DIMM it is
replacing.
For DIMM socket population rules, see “DIMM Population Rules” on page 79.
3.
Install a DIMM.
a.
Ensure that the ejector tabs are in the open position.
b.
Align the notch in the replacement DIMM with the connector key in the
connector socket.
The notch ensures that the DIMM is oriented correctly.
c.
Push the DDR4 DIMM into the connector socket until the ejector tabs lock
the DIMM in place.
84 Oracle Exadata Storage Server X5-2 High Capacity Service Manual • January 2018
