Install a Fan Module
Related Information
■
“Install a Fan Module” on page 70
Install a Fan Module
1.
Remove the replacement fan module from its packaging, and place it on an
antistatic mat.
2.
With the top cover fan assembly door open, install the replacement fan module
into the server [1].
The fan modules are keyed to ensure that they are installed in the correct orientation.
3.
Press down on the fan module and apply firm pressure to fully seat the fan
module.
70 Oracle Exadata Storage Server X5-2 High Capacity Service Manual • January 2018
