Servicing the Internal USB Flash Drive
b.
Install the top cover.
See “Install the Server Top Cover” on page 161.
c.
Return the server to the normal rack position.
See “Return the Server to the Normal Rack Position” on page 165.
d.
Connect any required data cables to the PCIe card.
Route data cables through the cable management arm.
e.
Reconnect the power cords to the power supplies and power on the server.
See “Reconnect Power and Data Cables” on page 167 and “Power On the
Server” on page 167. Verify that the AC OK LED is lit.
7.
Use Oracle ILOM to clear any server PCIe card faults.
You can use the Oracle ILOM web interface or the command-line interface (CLI) to manually
clear faults. For information on how to use the Oracle ILOM web interface or the CLI to clear
server faults, see the Oracle Integrated Lights Out Manager (ILOM) 3.2 Documentation Library
at:
http://www.oracle.com/goto/ilom/docs.
8.
To determine whether additional steps are required to complete the installation
of the PCIe card, refer to the storage server product notes for the type of PCIe
card you installed.
Related Information
■
“PCIe Slot Locations” on page 87
■
“Remove a PCIe Card” on page 88
Servicing the Internal USB Flash Drive
Caution - These procedures require that you handle components that are sensitive
to electrostatic discharge. This sensitivity can cause the component to fail. To avoid
damage, ensure that you follow antistatic practices as described in “Take Antistatic
Measures” on page 57.
92 Oracle Exadata Storage Server X5-2 High Capacity Service Manual • January 2018
