Assign Serial Port Output Using the Web Interface
Note - The serial port sharing value by default is owner=SP.
3.
Connect a serial host to the server.
Assign Serial Port Output Using the Web Interface
1.
Log in to the SP Oracle ILOM web interface.
To log in, open a web browser and direct it using the IP address of the server SP. Log in as root
or a user with administrator privileges. See “Accessing Oracle ILOM” in the Oracle X5 Series
Servers Administration Guide.
The Summary Information screen appears.
2.
In the Oracle ILOM web interface, select ILOM Administration → Connectivity
from the navigation menu on the left side of the screen.
3.
Select the Serial Port tab.
The Serial Port Settings page appears.
Note - The serial port sharing setting by default is Service Processor.
4.
In the Serial Port Settings page, select Host Server as the serial port owner.
5.
Click Save for the changes to take effect.
6.
Connect a serial host to the server.
Ethernet Port Boot Order and Device Naming
This section contains information about the boot order and device naming for the four 10-
Gigabit Ethernet ports on the rear panel of the server. For location information, see “Rear Panel
Connector Locations” on page 39. From right to left, the ports are numbered NET 0 to NET
3.
Ethernet Port Boot Order
The order in which the BIOS detects the Ethernet ports during server boot is listed below.
42 Oracle Exadata Storage Server X5-2 High Capacity Service Manual • January 2018
