About System Components
Figure
Legend
Description
7 Oracle Integrated Lights Out Manager (ILOM) service processor (SP) network management
10/100/1000BASE-T port (NET MGT)
8 USB 2.0 ports (2)
9 DB-15 video connector
12 PCIe slot 6 (This slot contains the Oracle Storage 12 Gb SAS PCIe RAID HBA.)
13 Network (NET) 100/1000/10000 ports (NET3 - NET0)
14 System status LEDs: Locator/Button: white; Service Required: amber; Power/OK: green
15 - 16 Power supply unit 1 (PS1) and power supply unit 0 (PS0)
Related Information
■
“Troubleshooting Using the Server Front and Rear Panel Status Indicators ” on page 26
■
“Disconnect Cables From the Server” on page 54
■
“Reconnect Power and Data Cables” on page 167
■
“Identifying the Server Ports” on page 169
About System Components
These sections describe the components of the server:
■
“Illustrated Parts Breakdown” on page 16
■
“Field-Replaceable Units” on page 18
■
“Field-Replaceable Units” on page 18
Related Information
■
“Servicing Components That Do Not Require Server Power-Off” on page 61
■
“Servicing Components That Require Server Power-Off” on page 77
Illustrated Parts Breakdown
The following figure identifies the major components of the server.
16 Oracle Exadata Storage Server X5-2 High Capacity Service Manual • January 2018
