Monitoring System Components
Component Name (Oracle ILOM
CLI Targets)
IPMI Type Description Values (if applicable)
/SYS/MB/RHDD[0-1]/OK2RM Indicator Rear hard disk drive OK to
Remove LED
Color: Blue
Location: Rear HDD
Off: Normal
On: OK to remove
/SYS/MB/RHDD[0-1]/STATE Discrete
sensor
Rear hard disk drive state 02h-DRIVE_FAULT
04h-
PREDICTIVE_FAILURE
08h-HOT_SPARE
/SYS/DBP/HDD[0-x] FRU Hard disk drive FRU From host
/SYS/DBP/HDD[0-x]/PRSNT Discrete
sensor
Hard disk drive presence 01h-ENTITY_ABSENT
02h-ENTITY_PRESENT
/SYS/DBP/HDD[0-x]/STATE Discrete
sensor
Writable multistate, slot/
connector sensor type, per
IPMI
02h-DRIVE_FAULT
04h-
PREDICTIVE_FAILURE
08h-HOT_SPARE
/SYS/DBP/HDD[0-x]/SERVICE Indicator Hard disk drive Service
Required LED
Color: Amber
Location: HDD
Off: Normal
On: Hard disk drive was
diagnosed as faulty.
/SYS/DBP/HDD[0-x]/OK2RM Indicator Hard disk drive OK to
Remove LED
Color: Blue
Location: HDD
Off: Normal
On: OK to remove
/SYS/DBP/NVME[0-x] FRU NVMe drive FRU
/SYS/DBP/NVME[0-x]/PRSNT Discrete
sensor
PCIe NVMe drive 01h-ENTITY_PRESENT
02h-ENTITY_ABSENT
