Monitoring System Components
Component Name (Oracle
ILOM CLI Targets)
IPMI Type Description Values (if applicable)
/SYS/OK Indicator Power OK LED Color: Green
Location: Front panel
Off: Power is off.
Standby blink: Standby power is on;
Oracle ILOM SP is running.
Slow blink: Startup sequence
initiated on host.
On: Host is booting OS or running
the OS.
/SYS/SERVICE Indicator Service Required LED Color: Amber
Location: Front panel
Off: Normal
On: Server requires service.
/SYS/LOCATE Indicator Locator LED Color: White
Location: Front and rear panels
Off: Normal
Fast blink: Locate function is
activated; self-extinguishes after 30
minutes.
/SYS/HOST_ERR Discrete
sensor
Host asserted error sensor 01h-Deasserted
02h-Asserted
/SYS/PS_FAULT Indicator Rear Power Supply Fault LED Color: Amber
Location: Mainboard
Off: Normal
On: General power supply fault
/SYS/FAN_FAULT Indicator Top Fan Fault LED Color: Amber
Location: Mainboard
Off: Normal
On: General fan fault
Related Information
■
“Cooling Unit Components” on page 233
